REVISION
REV.
DESCRIPTION
DATE
APPROVED
TAPE
11
10
160 ± 20
P1
2
1
C4
C3
24
C5
C2
C1
16
8
3
4 5 6
7 8
3050 ± 80
9
3
1
8
16
9
2
1
24
P2
17
1
C1
17
9
FRONT
3.8 ± 0.3
DVI (24+5)P/M ASS’Y TYPE
3.8 ± 0.3
DVI (24+5)P/M ASS’Y TYPE
C2
C5
FRONT
C4
PIN OUT
P1
P2
P1
P2
P1
P2
1
2
3
4
5
9
10
11
12
13
WHITE
O RANG E
DRAIN
DRAIN
WHITE
B ROWN
WHITE
BLACK
DRAIN
DRAIN
WHITE
BLUE
1
2
3
4
5
9
10
11
12
13
6
7
17
18
19
20
21
22
23
24
WHITE
Y ELLOW
WHITE
YELLO W
DRAIN
DRAIN
WHITE
GREEN
DRAIN
WHITE
RED
6
7
17
18
19
20
21
22
23
24
C1
C5
C2
C5
C3
C5
C4
8
14
15
16
SHELL
RED
GREEN
BLUE
YELLOW
BLUE
RED
BLACK
BROWN
BRAID
C1
C5
C2
C5
C3
C5
C4
8
14
15
16
SHELL
No.
1
2
3
4
5
6
7
8
9
PARTS NAME
DVI (24+5)P/M - CONTACT
DVI (24+5)P/M - INSULATOR
DVI (24+5)P/M - SHELL
DVI (24+5)P/M - CAN
COPPER FOIL
DVI (24+5)P/M - COVER
THUMB SCREW
SCREW - MOLD
CABLE DVI 24+5 UL20276
SPECIFICATION STANDARD
BRONZE/GOLD PLATED SOLDER TYPE
THERMOPLASTIC/BLACK UL94V-0
NICKEL PLATED
STEEL TIN PLATED
WIDTH: 15mm
45P PVC/COLOR: BLACK
#4-40 2.8x45, NICKEL PLATED
35P PVC / COLOR: BLACK
KL03009ABK01A
QTY REMARKS
58
2
2
2
2
2
4
4
1
10
MINI TIE
PE/BLACK
2
NOTES:
11
POLYBAG
PE/0.08x220x250mm
1
1321029-10
1. CABLE: UL20276
[(28AWGx1P+DW+FOIL)x7+(28AWG+SP+FOIL)x3+28AWGx5C+28AWGx1P+MYLAR+FOIL+BD]x1
OUTER JACKET COLOR: BLACK, OD: 9.5 ± 0.3mm
PRINTING: “E166307 AWM 20276 28AWG 80?C 30V VW-1
LOW VOLTAGE COMPUTER CABLE
2. CONNECTORS: DVI (24+5)P/M - DVI (24-5)P/M
3. HOOD: ASS’Y TYPE. COLOR: BLACK
4. CABLE ELECTRICAL TEST:
<1>.100% OPEN SHORT & MISS WIRE TEST
Dim
range
(mm)
0-1
1-6
6-18
Tolerance
+/-
(mm)
0.15
0.20
0.30
Qualtek Electronics Corp.
WCI DIVISION
Part Number:
Description:
DVI (24+5)P/M - DVI (24-5)P/M
<2>. INSULATION RESISTANCE: DC400V 10M ohm MIN.
<3>. CONDUCTOR RESISTANCE: 3 ohm MAX.
5. PACKING: 1PC/POLYBAG
18-50
50-120
120-250
250-500
0.50
0.70
0.90
1.20
Drawn / Date
B. Grubb
01-25-07
Checked / Date
01-25-07
Approved / Date
JJH / 01-25-07
